One-touch tube fittings are used in
pneumatic piping.
The tube fittings come in a
wide variety of models to meet all your needs in
pneumatic piping.
Even after installation, the
direction of the tube can be changed
freely.
Nickel-pated metal body ensures
anti-corrosion and anti-contamination.
All R
and NPT threads are pre-coated
sealant. |
| |
|
 |
|
|
 |
|
|
|
|
| Fluid Type |
Air (No other type of gas or
liquid) |
| Working Pressure Range |
0~150PSI |
0~9.9KgF/cm2(0~990KPa) |
| Negative
Pressure |
-29.5 in Hg |
-750mm Hg(10
Torr) |
| Working
Temperature |
32~140°F |
0-60℃ |
|
 |
|
|
|
|
|
| |
|
|
|
|
|
 |
|
|
|
|
 |
 |
|
|
Metric Tube |
Code |
04 |
06 |
08 |
10 |
12 |
16 |
Size(mm) |
Φ4 |
Φ6 |
Φ8 |
Φ10 |
Φ12 |
Φ16 |
|
|
Metric Tube |
Taper pipe
Thred |
Code |
M5 |
M6 |
01 |
02 |
03 |
04 |
Size(mm) |
M5X0.8 |
M6X1.0 |
R1/8 |
R1/4 |
R3/8 |
R1/2 |
|
|
InchTube |
Code |
5/32 |
3/16 |
1/4 |
5/16 |
3/8 |
1/2 |
Size(mm) |
Φ5/32 |
Φ3/16 |
Φ1/4 |
Φ5/16 |
Φ3/8 |
Φ1/2 |
|
|
UNF Thread |
American Standard Taper pipe
Thread |
Code |
U |
N1 |
N2 |
N3 |
N4
|
Size(mm) |
10-32UNF |
NPT1/8 |
NPT1/4 |
NPT3/8 |
NPT1/2 |
|
| When (2) is thread size, choose
thread size from (3). |
|
When (3) is tube diameter,
choose tube diameter
from(2). |
|
| |
|
|
|
|
|
 |
|
|
|
No Code: Black Color
C:Grey
Color |
|
|
|
|
| |
|
|
|
|
|
| PC |
MODEL(φD-T) |
| Tube(Metric)-Thread(R) |
Tube(Inch)-Thread(R) |
Tube(Inch)-Thread(NPT) |
| PC04-M5 |
PC06-04 |
PC12-02 |
PC1/4-01 |
PC3/8-04 |
PC5/32-U |
PC1/4-N2 |
PC1/2-N2 |
| PC04-M6 |
PC08-01 |
PC12-03 |
PC1/4-02 |
PC1/2-02 |
PC5/32-N1 |
PC1/4-N3 |
PC1/2-N3 |
| PC04-01 |
PC08-02 |
PC12-04 |
PC1/4-03 |
PC1/2-03 |
PC5/32-N2 |
PC5/16-N2 |
PC1/2-N4 |
| PC04-02 |
PC08-03 |
PC12-03 |
PC5/16-01 |
PC1/2-04 |
PC3/16-U |
PC5/16-N3 |
|
| PC06-M5 |
PC08-04 |
PC12-04 |
PC5/16-02 |
|
PC3/16-N1 |
PC5/16-N4 |
|
| PC06-M6 |
PC10-01 |
|
PC5/16-03 |
|
PC3/16-N2 |
PC3/8-N1 |
|
| PC06-01 |
PC10-02 |
|
PC3/8-01 |
|
PC3/16-N3 |
PC3/8-N2 |
|
| PC06-02 |
PC10-03 |
|
PC3/8-02 |
|
PC
1/4U |
PC3/8-N3 |
|
| PC06-03 |
PC10-04 |
|
PC3/8-03 |
|
PC1/4N1 |
PC3/8-N4 |
|
|
|
| |
|
|
|
|
| PCF |
MODEL(φD-T) |
| Tube(Metric)-Thread(RC) |
Tube(Inch)-Thread(RC) |
Tube(Inch)-Thread(NPT) |
| PCF
04-01 |
PCF
10-01 |
PCF
1/4-01 |
PCF
5/32-N1 |
PCF
3/8-N2 |
| PCF
04-02 |
PCF
10-02 |
PCF
1/4-02 |
PCF
5/32-N2 |
PCF
3/8-N3 |
| PCF
06-01 |
PCF
10-03 |
PCF
5/16-01 |
PCF
3/16-N1 |
PCF
1/2-N2 |
| PCF
06-02 |
PCF
10-04 |
PCF
5/16-02 |
PCF
3/16-N2 |
PCF
1/2-N3 |
| PCF
06-03 |
PCF
12-02 |
PCF
3/8-02 |
PCF
1/4-N1 |
|
| PCF
08-01 |
PCF
12-03 |
PCF
3/8-03 |
PCF
1/4-N2 |
|
| PCF
08-02 |
PCF
12-04 |
|
PCF
5/16-N1 |
|
| PCF
08-03 |
|
|
PCF
5/16-N2 |
|
| PCF
08-04 |
|
|
PCF
5/16-N3 |
|
|
|
| |
|
|
| PL |
MODEL(φD-T) |
| Tube(Metric)-Thread(R) |
Tube(Inch)-Thread(R) |
Tube(Inch)-Thread(NPT) |
| PL
04-M5 |
PL
06-04 |
PL
12-02 |
PL
1/4-01 |
PL
3/8-04 |
PL
5/32-U |
PL
1/4-N2 |
PL
1/2-N2 |
| PL
04-M6 |
PL
08-01 |
PL
12-03 |
PL
1/4-02 |
PL
1/2-02 |
PL
5/32-N1 |
PL
1/4-N3 |
PL
1/2-N3 |
| PL
04-01 |
PL
08-02 |
PL
12-04 |
PL
1/4-03 |
PL
1/2-03 |
PL
5/32-N2 |
PL
5/16-N1 |
PL
1/2-N4 |
| PL
04-02 |
PL
08-03 |
PL
16-03 |
PL
5/16-01 |
PL
1/2-04 |
PL
3/16-U |
PL
5/16-N2 |
|
| PL
06-M5 |
PL
08-04 |
PL
16-04 |
PL
5/16-02 |
|
PL
3/16-N1 |
PL
5/16-N3 |
|
| PL
06-M6 |
PL
10-01 |
|
PL
5/16-03 |
|
PL
3/16-N2 |
PL
3/8-N1 |
|
| PL
06-01 |
PL
10-02 |
|
PL
3/8-01 |
|
PL
3/16-N3 |
PL
3/8-N2 |
|
| PL
06-02 |
PL
10-03 |
|
PL
3/8-02 |
|
PL
1/4-U |
PL
3/8-N3 |
|
| PL
06-03 |
PL
10-04 |
|
PL
3/8-03 |
|
PL
1/4-N1 |
PL
3/8-N4 |
|
|
|
| |
|
|
| PB |
MODEL(φD-T) |
| Tube(Metric)-Thread(R) |
Tube(Inch)-Thread(R) |
Tube(Inch)-Thread(NPT) |
| PB
04-M5 |
PB
06-04 |
PB
12-02 |
PB
1/4-01 |
PB
3/8-04
|
PB
5/32-U |
PB
1/4-N2 |
PB
1/2-N2 |
| PB
04-M6 |
PB
08-01 |
PB
12-03 |
PB
1/4-02 |
PB
1/2-02 |
PB
5/32-N1 |
PB
1/4-N3 |
PB
1/2-N3 |
| PB
04-01 |
PB
08-02 |
PB
12-04 |
PB
1/4-03 |
PB
1/2-03 |
PB
5/32-N2 |
PB
5/16-N1 |
PB
1/2-N4 |
| PB
04-02 |
PB
08-03 |
PB
16-03 |
PB
5/16-01 |
PB
1/2-04 |
PB
3/16-U |
PB
5/16-N2 |
|
| PB
06-M5 |
PB
08-04 |
PB
16-04 |
PB
5/16-02 |
|
PB
3/16-N1 |
PB
5/16-N3 |
|
| PB
06-M6 |
PB
10-01 |
|
PB
5/16-03 |
|
PB
3/16-N2 |
PB
3/8-N1 |
|
| PB
06-01 |
PB
10-02 |
|
PB
3/8-01 |
|
PB
3/16-N3 |
PB
3/8-N2 |
|
| PB
06-02 |
PB
10-03 |
|
PB
3/8-02 |
|
PB
1/4-U |
PB
3/8-N3 |
|
| PB
06-03 |
PB
10-04 |
|
PB
3/8-03 |
|
PB
1/4-N1 |
PB
3/8-N4 |
|
|
|
| |
|
|
| PX |
MODEL(φD-T) |
| Tube(Metric)-Thread(R) |
Tube(Inch)-Thread(R) |
Tube(Inch)-Thread(NPT) |
| PX
04-M5 |
PX
06-04 |
PX
12-02 |
PX
1/4-01 |
PX
3/8-04 |
PX
5/32-U |
PX
1/4-N2 |
PX
1/2-N2 |
| PX
04-M6 |
PX
08-01 |
PX
12-03 |
PX
1/4-02 |
PX
1/2-02 |
PX
5/32-N1 |
PX
1/4-N3 |
PX
1/2-N3 |
| PX
04-01 |
PX
08-02 |
PX
12-04 |
PX
1/4-03
|
PX
1/2-03 |
PX
5/32-N2 |
PX
5/16-N1 |
PX
1/2-N4 |
| PX
04-02 |
PX
08-03 |
|
PX
5/16-01 |
PX
1/2-04 |
PX
3/16-U |
PX
5/16-N2 |
|
| PX
06-M5 |
PX
08-04 |
|
PX
5/16-02 |
|
PX
3/16-N1 |
PX
5/16-N3 |
|
| PX
06-M6 |
PX
10-01 |
|
PX
5/16-03 |
|
PX
3/16-N2 |
PX
3/8-N1 |
|
| PX
06-01 |
PX
10-02 |
|
PX
3/8-01 |
|
PX
3/16-N3 |
PX
3/8-N2 |
|
| PX
06-02 |
PX
10-03 |
|
PX
3/8-02 |
|
PX
1/4-U |
PX
3/8-N3 |
|
| PX
06-03 |
PX
10-04 |
|
PX
3/8-03 |
|
PX
1/4-N1 |
PX
3/8-N4 |
|
|
|
| |
|
|
| PU |
MODEL(φD) |
| Tube(Metric) |
Tube(Inch) |
| PU
04 |
PU
5/32 |
| PU
06 |
PU
3/161 |
| PU
08 |
PU
1/ 4 |
| PU
10 |
PU
5/16 |
| PU
12 |
PU
3/ 8 |
PU
16
|
PU
1/
2 |
| |
|
|
|
| |
|
|
| PV |
MODEL(φD) |
| Tube(Metric) |
Tube(Inch) |
| PV
04 |
PV
5/32 |
| PV
06 |
PV
3/16 |
| PV
08 |
PV
1/ 4 |
| PV
10 |
PV
5/16 |
| PV
12 |
PV
3/ 8 |
| PV
16 |
PV
1/
2 |
| |
|
|
|
| |
|
|
| PE |
MODEL(φD) |
| Tube(Metric) |
Tube(Inch) |
| PE
04 |
PE
5/32 |
| PE
06 |
PE
3/16 |
| PE
08 |
PE
1/ 4 |
| PE
10 |
PE
5/16 |
| PE
12 |
PE
3/8 |
| PE
16 |
PE
1/2 |
| |
|
|
|
| |
|
|
| PY |
MODEL(φD) |
| Tube(Metric) |
Tube(Inch) |
| PY
04 |
PY
5/32 |
| PY
06 |
PY
3/16 |
| PY
08 |
PY
1/ 4 |
| PY
10 |
PY
5/16 |
| PY 12 |
PY
3/ 8 |
|
PY
1/
2 |
| |
|
|
|
| |
|
|
| PG |
MODEL(φD1-φD2) |
| Tube(Metric) |
Tube(Inch) |
| PG
06-04 |
PG
3/16-5/32 |
| PG
08-06 |
PG
1/4-5/32 |
| PG
10-08 |
PG
1/4-3/16 |
| PG
12-10 |
PG
5/16-1/4 |
| PG
16-12 |
PG
3/8-5/16 |
|
PG
1/2-3/8 |
| |
|
|
|
| |
|
|
| PEG |
MODEL(φD1-φD2) |
| Tube(Metric) |
Tube(Inch) |
| PEG
06-04 |
PEG
1/4-5/32 |
| PEG
08-06 |
PEG
5/16-1/4 |
| PEG
10-08 |
PEG
3/8-5/16 |
| PEG
12-10 |
PEG
1/2-3/8 |
| PEG
16-12 |
|
| |
|
| |
|
|
|
| |
|
|
| PM |
MODEL(φD) |
| Tube(Metric) |
Tube(Inch) |
| PM
04 |
PM
5/32 |
| PM
06 |
PM
3/16 |
| PM
08 |
PM
1/4 |
| PM
10 |
PM
5/16 |
| PM
12 |
PM 3/
8 |
|
PM
1/2 |
| |
|
|
|
| |
|
|
| PLF |
MODEL(φD-T) |
| Tube(Metric)-Thread(RC) |
Tube(Inch)-Thread(NPT) |
| PLF
04-M5 |
PLF
08-01 |
PLF
12-03 |
PLF
5/32-N1 |
PLF
3/8-N3 |
| PLF
04-M6 |
PLF
08-02 |
PLF
12-04 |
PLF
3/16-N1 |
PLF
1/2-N3 |
| PLF
04-01 |
PLF
08-03 |
|
PLF
3/16-N2 |
PLF
1/2-N4 |
| PLF
04-02 |
PLF
08-04 |
|
PLF
1/4-N1 |
|
| PLF
06-M5 |
PLF
10-01 |
|
PLF
1/4-N2 |
|
| PLF
06-M6 |
PLF
10-02 |
|
PLF
5/16-N1 |
|
| PLF
06-01 |
PLF
10-03 |
|
PLF
5/16-N2 |
|
| PLF
06-02 |
PLF
10-04 |
|
PLF
5/16-N3 |
|
|
|
| |
|
|
| PZA |
MODEL(φD) |
| Tube(Metric) |
Tube(Inch) |
| PZA
04 |
PZA
5/32 |
| PZA
06 |
PZA
3/16 |
| PZA
08 |
PZA
1/ 4 |
| PZA
10 |
PZA
5/16 |
| PZA
12 |
PZA
3/ 8 |
|
PZA
1/
2 |
| |
|
|
|
| |
|
|
| PP |
MODEL(φD) |
| Tube(Metric) |
Tube(Inch) |
| PP
04 |
PP
5/32 |
| PP
06 |
PP
3/16 |
| PP
08 |
PP
1/ 4 |
| PP
10 |
PP
5/16 |
| PP
12 |
PP
3/ 8 |
| PP
16 |
PP
1/
2 |
| |
|
|
|
| |
|
|
| PK |
MODEL(φD) |
| Tube(Metric) |
Tube(Inch) |
| PK
04 |
PK
5/32 |
| PK
06 |
PK
3/16 |
| PK
08 |
PK
1/4 |
|
PK
5/16 |
| |
|
| |
|
| |
|
|
|
| |
|
|
TUBE FITTINGS WITH G THREAD (O-RING) |
| |
|
|
| PCF-G |
MODEL(φD-T) |
| Tube(Metric)-Thread(G) |
| PCF
04-G01 |
PCF
10-G02 |
| PCF
04-G02 |
PCF
10-G03 |
| PCF
06-G01 |
PCF
10-G04 |
| PCF
06-G02 |
PCF
12-G02 |
| PCF
06-G03 |
PCF
12-G03 |
| PCF
08-G01 |
PCF
12-G04 |
| PCF
08-G02 |
|
| PCF
08-G03 |
|
| PCF
08-G04 |
|
| PCF
10-G01 |
|
|
|
